SM-VM-ART1-IW-M | Strong™ VersaMount™ Single-Arm In-Wall Articulating Mount
Strong® VersaMount™ Single-Arm In-Wall Articulating Mount
The VersaMount is Strong's best and most versatile mount yet, setting a new standard in low-profile articulation. With the ability to position TVs from flush to 16” off the wall, these mounts are our most premium and versatile mounts to date. It features up to 5” of vertical post-install height adjustment and 11 degrees of roll adjustment with precision TorcMotion technology.
It also combines the convenience of an integrated VersaBox for cleaner and sleeker installs. For a premium, precision-engineered install, look no further than the Strong VersaMount.


|
SM-VM-ART1-IW-M |
SM-VM-ART1-IW-16-L |
Maximum TV Size |
55" |
80" |
Minimum TV Size |
24" |
40" |
Weight |
Capacity: 50 lb |
Capacity: 100 lb |
Tilt |
+19° / -3° |
+19° / -3° |
Roll |
+10° / -10° |
+10° / -10° |
Swivel |
Pan/Swivel Range: 180° |
Pan/Swivel Range: 180° |
Post Install Height Adjustment |
2" |
5" |
Distance Extended |
16" |
16" |
Distance Retracted |
0.5" |
0.5" |
VESA Mounting Pattern |
75x75, 100x100, 100x200, 200x100, 200x200, 200x300, 300x200, 300x300 |
75x75, 100x100, 100x200, 200x100, 200x200, 200x300, 300x100, 300x200, 300x300, 300x400, 400x100, 400x200, 400x300, 400x400 |
Certifications |
cULus, RoHs |
cULus, RoHs |
|
|
