ALTV248UL
UL/CUL Listed CCTV AC Wall Mount 8 Output Power Supply
Overview
Model ALTV248UL provides 24VAC distributed via eight (8) fuse protected outputs. |
| |
Agency Listings
• UL Listed for Commercial CCTV Equipment (UL2044),
CUL Listed - CSA Standard C22.2 No.1-98, Audio, Video
and Similar Equipment.
• CE Approved.
Features/Specifications
• 24VAC or 28VAC output.
• 3.5 amp @ 24VAC or 3 amp @ 28VAC (85VA) supply current.
• Eight (8) fuse protected outputs.
• Output fuses are rated @ 3.5 amp.
• 115VAC 50/60Hz, .9 amp input.
• In-line fuse is rated @ 3.5 amp.
• Surge suppression.
• AC power LED indicator.
• Power ON/OFF Switch.
• Unit maintains camera synchronization.
• Lifetime Warranty.
Enclosure
• Dimensions: 8.5”H x 7.5”W x 3.5”D.
• 1/2" and 3/4" combination knockouts.
Applications
• 24VAC or 28VAC power for CCTV cameras, heaters, and other video accessories.
|
