Feature List
- 2-way system with dual 6.5" woofers
- 6200e C uses identical drivers as LR for ideal tonal match
- Acoustic controls optimize performance in any room
- Recommended 4200e SR dipole/bipole switchable surround speakers
- Optional sand-fillable Peds raise LRs to optimum listening height
- Recommended subwoofer: THX-certified 642e SB
Specifications
| Model |
6200e LR |
6200e C |
4200e SR |
| Type |
Sealed-box, 2-way |
Sealed-box, 2-way |
Sealed-box, 2-way
Dipole/Bipolesurround speaker |
| Drivers |
|
|
|
| Woofer |
(2) 6.5" GLH |
(2) 6.5" GLH |
(2) 4.5" GLH |
| Tweeter |
(1) 1" silk dome |
(1) 1" silk dome |
(2) 1” silk dome |
| Frequency Response |
60Hz – 20kHz ±2dB |
60Hz – 20kHz ±2dB |
80Hz – 20kHz ±2dB |
| Nominal Impedance |
6Ω |
6Ω |
6Ω |
| Crossover Frequency |
3kHz |
3kHz |
3kHz |
| Crossover Type |
Computer designed Butterworth 4th order asymmetrical (time-aligned)
Linkwitz-Riley |
| Sensitivity |
90dB |
90dB |
89dB |
| Recommended Amplifi er Power |
15 – 150 Watts RMS |
15 – 150 Watts RMS |
15 – 150 Watts RMS |
| Magnetic Shielding |
Yes |
Yes |
No |
Dimensions w/ grilles(W x H x D)
|
9.1 x 23.1 x 11.5in
231 x 587 x 292mm |
21.5 x 11.1 x 12in*
547 x 282 x 305mm* |
10.9 x 12.4 x 7.5in
277 x 315 x 191mm |
| |
Pedestals including feet, spikes, and gap between satellite and pedestal top adds height: |
| |
23.9in., 608mm |
|
|
| Weight (ea) |
26.0lbs; 11.8kg |
25.0lbs; 11.3kg w/base |
11.0lbs; 5kg |
|
