This powerful processor provides automation of a wide array of electronic systems such as audio, video, lighting, HVAC, security, and more. Choose music and movies from various sources, turn lights on and off, change temperature, control shades and door locks, and more.

IP-Based Automation and Flexibility
As an IP network-based processor, this piece can sit in any room in the house or a central equipment rack and provide ultra-fast control and response time with 100% accuracy. Because it lives on the home network, wiring, adding components and servicing are easier than ever and automation possibilities are virtually limitless.

Easy Expansion for the Future
The URC CP-1 offers the finest in expansion. It can handle one room to many, and expand to the outdoors and off-premises. Using ccGEN2 remotes or an app, control is simple and every family member gets what they want with one press on a remote, smartphone or tablet. Plus, this processor sets the stage for the future. Additional third-party subsystems can be added with ease. Being IP-based, it can handle most any technology or product that comes down the pike. With the CP-1 you can offer every client affordable, two-way home automation with the URC renowned experience.

KEY FEATURES / SPECIFICATIONS
 Stores and issues commands and macros via IR, IP, RS-232, and Relays
 Provides two-way communication with ccGEN2 remotes, apps and keypads
 Routes commands to auxiliary pieces (AC-1 Auxiliary Controller and WC-1 Wireless Controller)
 Provides automation via user scheduled events or by sensors connected to onboard sensor ports
 Off-site programming capable when system is registered
 CP-1 is required in ccGEN2 systems; maximum one per system

 Network: One (1) 10/100 Ethernet port
 IR: Six (6) adjustable IR ports powered by independent IR Engines for simultaneous use
 Relays: One (1)
 RS-232: Two (2) ports (support TX, RX and GND two-way communication)
 Sensors: Two (2) sensor ports
 Power: 12v external power supply
 Size: 9.8”(W) x 1.1”(H) x 4.7” (D)
 Weight: 10.5 oz.
 Warranty: One Year USA Limited Warranty

Easily expand your ccGEN2 system by adding...
 Mobile app for iOS devices
 RF Remote for basic control with antenna (RM-1 and AZ-1)
 Auxiliary Controller for in-room control as a sub-base station for IR, RS-232, Relay control (AC-1)
 Z-Wave® Extender for Z-Wave-enabled devices suchas door locks, lighting and thermostats (TRF-ZW1)

 URC Sensors for enhanced automation (MRX-4SEN and sensors)
 And more! (See ccGEN2 Full System Diagram for more info)
