Item #: SC532W
MSRP: No Retail
Login


1.3 MP Mini Dome IP Camera w/POE – SC532W



Channel Vision’s 1.3 MP Mini Vandal Proof IP Dome Camera offers superior image quality with a 1.3 megapixel CMOS sensor and has the ability to deliver images up to 720p (1280×800 pixels) at 30 frames per second. The SC532W's advanced features like Digital Wide Dynamic Range, Triple Streaming, Power Over Ethernet, Digital Noise Reduction and its IP66 Rated design makes it the perfect camera for all conditions. View and control the SC543W anywhere in the world with an internet browser(only Internet Explorer supported) or Channel Vision’s iOS and Android applications. Power supply 5015PS NOT Included.



HARDWARE

CPU: ARM 9 ,32 bit RISC
RAM: 128MB
Flash: 16MB
Image Sensor: 1 / 4” 1.3 Mega-Pixel CMOS sensor
Sensitivity: 1.0 Lux @30fps
Shutter Time: 1 / 5 ~ 1 / 10,000 sec
Lens Type: 4.2mm@F1.6
I/O: DI/DO
Power Over Ethernet: Yes, 48V Power consumption, Max: 2.8W
Power: DC12V Power consumption, Max: 2.04W, 170mA
IP66 Water Proof Rating: Yes
Operating Temperature: -10°C ~ 45°C
Dimensions: 3.15” DIA x 2.64” H
Weight: 11.99 ounces

SYSTEM

Video Resolution: 1280×800@30fps,1280×720@30fps ,
640×480@30fps, 320×240@30fps, 176×144@30fps
Video Adjust: Brightness, Contrast, Hue, Saturation, Sharpness, AGC,
Shutter Speed adjustable, Sense-Up, D-WDR, Flip, Mirror, Noise reduction, DNR
Triple Streaming: Yes
Image Snapshot: Yes
Full Screen Monitoring: Yes
Privacy Mask: Yes, 3 different areas
Compression Format: H.264/ M-JPEG/ MPEG4
Video Bitrates Adjust: CBR, VBR
Motion Detection: Yes, 3 different areas
Triggered Action: Mail, FTP, Save to SD card, SAMBA
Security: Password protection, IP address filtering, HTTPS encrypted data transmission,
802.1X port-based authentication for network protection, QoS/DSCP
Firmware Upgrade: HTTP mode, can be upgraded remotely
Simultaneous Connection: Up to 10

NETWORK

Ethernet: 10/ 100 Base-T
Network Protocol: HTTP, HTTPS, SNMP, QoS/DSCP, Access list,
IEEE 802.1X, RTSP, TCP/IP, UDP, SMTP, FTP, PPPoE, DHCP, DDNS, NTP,
UPnP, 3GPP, SAMBA, Bonjour

MICRO SD CARD MANAGEMENT

Recording Trigger: Motion Detection, IP check, Network break down, Schedule
Video Format: AVI, JPEG
Video Playback: Yes
Delete Files: Yes

REMOTE VIEWING

OS: Windows 2000, XP, Vista, 7
Browser: Microsoft IE 6.0 or above Safari, Chrome
Smartphone & Tablet: iOS and Android
