SI Elite Series Front Door Intercom (Satin Nickel)

Channel Vision’s SI Elite Series Door Station interfaces with Channel Vision’s Telephone Entry Controllers to provide amplified 2-way communication with one or more doors. The SI series door station features your choice an optional hidden 960H analog camera, as well as an illuminated door bell button for enhanced visibility at night. The SI-6000 series now contains Channel Vision’s newest circuit board that allows for more clear communication and volume control than previous models.

Compatible with P-0920 and P-0921 Hidden 960H High Resolution Camera New circuit board provides enhanced 2-way communication Illuminated door bell button for visibility at night

Elite Series Intercom Key Features

• 1/4” thick solid brass plate
• Discrete speaker and microphone
• Fits the DP-Rbox-III flush mount box, and the DP-9001, DP-9002 surface mount boxes
• Available in 8 different finishes
• Dimensions: 6.5”L x 4.375”W x .25”D

Speaker Size (mm): 50 Depth (in.): 1.5” Impedance: 8 Ohms Power Peak (W): 0.2 Frequency Range: 500 Hz - 4.5 kHz Dimensions Surface Mount Box (included): 4.375” L x 1.75”W x 6.4375”H Flush Mount Box (not included): 3.5” L x 3.1”W x 5.75”H Door Plate: 4.375” x 6.4375” PCB Surface: Waterproof Silicon protected SI Series Doorplate Surface: Solid Brass, coated & protected Button Color: Blue LEDs Button Power: 12vDC 150mA

Color Camera Signal System: NTSC Total Pixels: 1020 (H) x 508 (V) 520K Effective Pixels: 976 (H) x 494 (V) 480K Image Sensor: 1/3” 960H Super HD CCD II (Sony) Lens: Pinhole, 5.5 mm Signal Processing: Digital Scanning System: 2:1 Interlace Sync System: Internal Scanning Frequency: 59.94 Hz (VD) Resolution: 700 TV Lines Video Output: 1.0 Vpp Composite (75 Ohms) Min. Illumination: 0.0002 Lux@Sense-up Shutter: Automatic Power Consumption: 12vDC 300mA total with butto
