DW-BJBLADE - Network Video Recorder
The Blackjack NVR powered by DW Spectrum is a powerful and user-friendly video management solution, highly optimized to provide unlimited scalability, unmatched bandwidth savings and simplified system setup and management. The architecture is cross-platform supporting both Windows and Linux
Features
|
- Graphical System Health Monitoring
- Simple Enterprise Scalability
- Fully Customizable Layouts
- Easy Drag-n-Drop Camera Management and Recording
- Advanced Motion Masking and Sensitivity Settings
- PTZ Control
- Instant Motion-Based Smart Search
- Advanced Thumbnail Search and Calendar Search
- Dual Stream Recording
- Automatic Device Discovery and Display
- HD (1080p) Screen Recording
- Panic Recording
- ONVIF Conformant
SPECIFICATIONS
|
| Operating System |
Linux |
| Channels |
16 |
| Video Input (BNC) |
Network Connection |
| Video Output |
VGA Out |
VGA, HDMI |
| Tv Out |
N/A |
| Display Speed (NTSC/PAL) |
Full HD up to 1080P |
| Record Speed (NTSC/PAL) fps max. |
full resolution up to 30fps |
| Compression Type |
H.264 |
| Post Alarm Recording |
Yes |
| Pre Alarm Recording |
Yes |
| Pre Alarm Recording SEC |
3~20 Seconds |
| Recording Mode |
Continuous, Motion, Motion + Continuous at Low Resolution. |
| Recording Resolution |
NTSC |
Up to 20 Megapixel |
| PAL |
N/A |
| Motion Detection |
Yes |
| Search |
Calendar Search, Thumbnail Search, Smart Motion Search, Single Channel Search in Live Mode, Frame-by Frame, Preview Search, Quick Time Bar Search |
| Water Marking |
Yes |
| Save Mode |
Export single or multiple channels video (AVI, EXE, MKV format).
Export Images (JPEG format).
Export Screen recording (AVI format). |
| Multi-Screen Display |
Fully Customizable Layouts |
| Pan Tilt/Zoom |
Coming Soon |
| Digital Zoom |
Yes |
| Audio Input (RCA) |
Yes |
| Audio Output |
Coming Soon |
| Default Storage (HDD) |
2 HDDs- 2TB |
| Storage Expandability - Internal |
No |
| Storage Expandability - External |
Coming Soon |
| Backup |
Coming Soon |
| Export Device |
USB, SD Card |
| Multiple User Authorization |
Yes |
| Multiple Level Security Access |
Yes |
| Remote Operation Configuration |
Yes |
| Wireless Remote Control |
Yes |
| Network |
1 X Gigabit LAN, 10/100/1000 Mbit/s (Wake-On-LAN; PXE) Wireless 1 X Wi-Fi 802.11 b/g/n (10/100/1000 Mbit/s Wakeon-WLAN) |
| Web Server |
Yes |
| Language Supported |
English |
| Warranty (Limited) |
Five (5) Years Limited |
| Case Size |
9.92(L) x 1.516(W) x 6.378(H) (inch) |
| Case Weight |
4.63 lbs |
| Available Models |
DW-BJBLADE |
| |
|
|
| |
|
