Evolution HDMI® 4 x 4 Multi-format Matrix with Video Wall and Seamless Multiview
- High-performance matrix with multiple modes to produce seamless matrix switching, as well as having multiview, and video wall modes
- The switching mode of the matrix allows the speed of switching to be controlled allowing inputs to fade in and fade out
- Multiview mode allows all of the sources to be seen on the displays equally in Quad-view, or in PIP with a main source being larger than the other smaller sources
- Video Wall mode allows the matrix to be configured to fit a 2x2 video wall with vertical and horizontal adjustments to account for different sized display bezels
- Built-in scaler function to achieve a variety of formats to a unified output signal with embedding audio.
- Supports RS-232, remote control, on-panel control and TCP/IP Control
- HDMI1.3, DVI1.0, and HDCP Compliant
- Input video supports HDMI, VGA and C-video
- Supports input resolutions: HDMI: 480i to 1080p, VGA:1920 x 1080P@60Hz, 1360 x 768P@60Hz, 1280 x 1024P@60Hz, 1024 x 768P@60Hz, 1280 x 720P@60Hz, 1280 x 768P@60Hz, 800 x 600@60Hz, 640 x 480P@60Hz, CV: Supports PAL, NTSC3.58, NTSC4.43, SECAM, PAL/M, PAL/N standard TV formats
- Supports smart EDID management
- Picture Adjustment Settings
- Automatically adjust the VGA and Composite video input
- Supports power-off memory
- Power Supply: 12V/2.5A DC
- Dimensions: 17.32” W x 1.75” H x 7.87” D
