HDBaseT™ 4K@60Hz, 4:4:4 Chroma, HDR Extender

• Features the latest HDBaseT Technology, optimized for whole-home or commercial distribution of highdefinition signals at much greater distances of standard HDMI cables
• Transmission Range: Extends 4K@60Hz, 4:4:4 with HDR up to 164ft/50m over a single Cat5e/6 cable and 1080p@60Hz up to 230ft/70m
• Features Power over Cable technology (PoC) which transmits power over Cat5e/6, allowing for either Transmitter or Receiver to be powered without the use of a power supply
• Virtually Lossless Compression retains high end audio and video quality
• Bi-directional IR control
• Features Auto EDID and EQ Management for plug and play installation
• HDR Compatible
• HDCP 2.2 compliant and backward compatible to previous versions
• CEC Support
• Slim and compact design
• Power Supply: DC 12V, 2A
• Dimensions: 5.75” W x .7” H x 3.7” D

Package Contents:

HDBT4K50 (TX & RX)
IR Transmitter (IR TX)
IR Receiver (IR RX)
Mounting Hardware
(1) DC 12V Power Supply
Product Manual
