Luma Surveillance™ 510 Series Turret Analog Camera
LUM-510-TUR-A-WH
The Luma 510 series turret camera offers 3MP of resolution, projecting higher video quality than 1080p. Its motorized varifocal lens gives you the capability to easily adjust the camera from the ground, making installation stress-free. 40 meters of IR Night Vision means your customers will be able to catch the highest quality footage at any time, day or night.
Important Note - HD-TVI - This camera uses an advanced version of HD-TVI technology in order to enable resolutions higher than 1080p. As a result, it does not work with older DVRs such as the Luma 500/501 DVRs.
Compatibility - This camera model is not compatible with our current Wirepath CCTV tester (WPS-CCTV-TESTER)
Key Features
Better Than HD
With 3MP, your customer’s video footage will record at a quality that bests even 1080p. The 510 series Luma cameras capture every nuance, so your customers can feel secure.
Easy Installation
Once the camera is properly aimed, you don’t have to worry about adjusting the focus from the ladder. The motorized varifocal lens can adjust the zoom and focus right from your computer or DVR, making installation a breeze.
Low-Maintenance
Luma turrets offer ease of install and are less susceptible to IR glare from dirt and dust that might accumulate over time, making them easy to care for.
IR up to 130’
This camera’s powerful IR lights up even the darkest night. With up to 40 meters or 130 feet of IR, it eliminates overexposure in dim settings and illuminates the subject, making sure your customers don’t miss a thing.
Optimize OSD After Dark
Need to fine-tune OSD settings after dark, but don’t want to roll a truck? Just log in remotely to the DVR. Our recorders feature built-in control thanks to HD-TVI technology.
Custom Settings for Day or Night
Set the optimal custom levels for any time of day.
Wide Dynamic Range
WDR, or Wide Dynamic Range, autocorrects images taken in inconsistent lighting and balances them into a clear picture.
Dual Voltage
In addition to 12VCD, this camera also supports 24VAC power, so you can easily run your power cables over a longer distance.
Weatherproof IP 66 Rating
We build our camera housing so that it can withstand the elements. You can rest assured that a strong storm or heavy rains will not impact the camera’s performance.
Certifications |
|
CE / FCC / UL |
Color |
|
White |
Dimensions (W x H x D) |
|
134.3mm×123.9mm×111.4mm |
Power Consumption |
|
Max. 6W |
Aspect Ratio |
|
16:9 |
Backlight Compensation |
|
Yes |
IR Range |
|
40m |
Mirror Mode |
|
Yes |
Sense-Up (Elec. Shutter) |
|
No |
Smart IR |
|
Yes |
Weather Rating |
|
IP66 |
Port Desc. |
|
Local Power Test Port: Yes
Local Video Test Port: Yes |
IR Wavelength |
|
850nm |
Field of View |
|
Horizontal: 83°-26.8° |
Power |
|
Power 12 VDC Support: Yes
Power 24 VAC Support: No |
IR Auto Switch |
|
Yes |
Image Sensor |
|
3MP (2052 x 1536 resolution) |
Lens |
|
2.8 mm to 12 mm motorized vari-focal lens |
Minimum Illumination |
|
0.01 lux @ ƒ/1.2, AGC on, 0 lux with IR |
WDR |
|
True WDR |
DNR |
|
2D-DNR |
Operating Temperature |
|
-22 to +140° |
5-Year Limited Warranty
Luma Surveillance™ Analog cameras have a 5-Year Limited Warranty. The warranty includes parts and labor repairs on all components found to be defective in material or workmanship under normal conditions of use. This warranty shall not apply to products that have been abused, modified, disassembled, or improperly installed. Products to be repaired under this warranty must be returned to SnapAV or a designated service center with prior notification and an assigned return authorization number (RA).
