Luma Surveillance™ 710 Series Turret Analog Camera with Heater



With 5MP of resolution, the Luma 710-series turret analog cameras will stun you with their ultra-sharp picture quality. Starlight and 40 meters of IR Night Vision mean your customers can be aware of what’s happening on their property at all hours, day or night. Its motorized varifocal lens gives you the capability to easily adjust the camera from the ground, making installation stress-free.




HD-TVI - This camera uses an advanced version of HD-TVI technology in order to enable resolutions higher than 1080p. As a result, it does not work with older DVRs such as the Luma 500/501 DVRs.

Compatibility - This camera model is not compatible with our current Wirepath CCTV tester (WPS-CCTV-TESTER)


Key Features


Ultra-Sharp Resolution

5MP delivers footage that will wow your customers. With resolution even higher than 1080p, our 710 series cameras offer among the best analog video quality.



Improved Night Vision

Great daytime shots are nice, but Starlight improves nighttime performance – a critical time for capturing surveillance footage. These cameras automatically adapt to changes in light. With enough ambient light, Starlight technology can provide a detailed color image, improving nighttime clarity.


Luma turrets offer ease of install and are less susceptible to IR glare from dirt and dust that might accumulate over time, making them easy to care for.

Withstands the Elements

These cameras are outdoor-rated and perform in extreme low-temperature environments – down to -40° Fahrenheit, as long as they’re continually powered.

Easy Installation

Once the camera is properly aimed, you don’t have to worry about adjusting the focus from the ladder. The motorized varifocal lens can adjust the zoom and focus right from your computer or DVR, making installation a breeze.

IR up to 130’

When there’s not enough light for Starlight, this camera’s powerful IR lights up even the darkest night. With up to 40 meters or 130 feet of IR, it eliminates overexposure in dim settings and illuminates the subject, making sure your customers don’t miss a thing.





Custom Settings for Day or Night

Set the optimal custom levels for any time of day.


Wide Dynamic Range

WDR, or Wide Dynamic Range, autocorrects images taken in inconsistent lighting and balances them into a clear picture.



Dual Voltage

In addition to 12VCD, this camera also supports 24VAC power, so you can easily run your power cables over a longer distance.


Weatherproof IP 66 Rating

We build our camera housing so that it can withstand the elements. You can rest assured that a strong storm or heavy rains will not impact the camera’s performance.



  CE / FCC / UL
Dimensions (W x H x D)
  134.3 mm × 123.9 mm × 110.1 mm
Power Consumption
  Max. 9W
Aspect Ratio
Backlight Compensation
IR Range
Mirror Mode
Sense-Up (Elec. Shutter)
Smart IR
Weather Rating
IR Wavelength
Field of View
  Horizontal: 102°-31°
  Power 12 VDC Support: Yes
Power 24 VAC Support: Yes
IR Auto Switch
Image Sensor
  5MP (2560 x 1944 resolution)
  2.8 mm to 12 mm motorized vari-focal lens
Minimum Illumination
  Color: 0.008 Lux @ (F1.2, AGC ON), 0 Lux with IR
Operating Temperature
  -40 to +140°


The future of surveillance has arrived.

Learn More About Luma

5-Year Limited Warranty

Luma Surveillance™ Analog cameras have a 5-Year Limited Warranty. The warranty includes parts and labor repairs on all components found to be defective in material or workmanship under normal conditions of use. This warranty shall not apply to products that have been abused, modified, disassembled, or improperly installed. Products to be repaired under this warranty must be returned to SnapAV or a designated service center with prior notification and an assigned return authorization number (RA).
