OCTOPOWER™ 850

The Octopower is a commercial multi-channel power amplifier designed for fixed installation in integrated systems. The Octopower includes nine discreet power amplifier channels, each with 50 watts of full bandwidth power into a 4-ohm load. Any combination of two amplifier channels can be bridged for multiple configurations. In its maximum bridged configuration, the Octopower provides one 50-watt channel at 4 ohms and four 100-watt channels at 8 ohms. Also included is a powerful Fault Contact feature with high-current Form C contacts. The Fault Contacts can be used for switching alarm and supervisory systems. All connections are located on the rear panel, and a removable AC power cable is included. Audio level control is recessed and located on the rear panel for tamper-resistant installation. Front-panel features include visual monitoring of fault status and audio levels for all nine channels. The Octopower also features forced-air cooling and is built into a standard 2RU EIA package designed for rack mounting. The Octopower is compatible with MediaMatrix® systems.

• - Balanced line level inputs
• - 50 watts RMS at 4 ohms per channel (x9)
• - Bridgeable
• - 2RU EIA rack package
• - Forced-air cooling
• - Recessed rear-panel level controls
• - Visual front-panel power status LED
• - Front-panel fault monitoring
• - Rear-panel high current fault contacts (Form C)
• - Heavy duty CRS construction
• - Nine discreet audio power amplifiers
• - Made in the U.S.A.
• - Weight Unpacked: 24.70 lb(11.203 kg)
• - Weight Packed: 30.00 lb(13.608 kg)
• - Width Packed: 5.25"(13.335 cm)
• - Height Packed: 23.5"(59.69 cm)
• - Depth Packed: 19.25"(48.895 cm)
