BLX1 Wireless Bodypack Transmitter for PG, SM and Beta Wireless

Description

The BLX1 bodypack has a lightweight and durable design. Ergonomically designed to fit comfortably in hand, with adjustable gain control. The BLX1 bodypack transmitter is included in PG, SM and Beta Analog Wireless Systems. You will get up to 14 hours of continuous use using 2 x AA batteries (included) and an operating range of 100m.

Features

• Power and battery status LED
• Adjustable gain control
• Quick and easy frequency matching
• AA batteries (included) provide up to 14 hours of continuous use
• 100 m (300 ft.) operating range (line of sight)

Specs

• Dimensions: 110 mm x 64 mm x 21 mm (H x W x D)
• RF Output Power: 10 mW, typical varies by region
• Battery, endurance: 2AA, up to 14 hours (alkaline)
• Weight: 75 g, without batteries g
• Further technical specifications:
  • Audio Input Level:
    • - gain max: -16 dBV maximum
    • - gain min (0 dB): +10 dBV maximum
  • Gain Adjustment Range: 26 dB
  • Input Impedance1 MΩ
  • RF Transmitter Output: 10 mW, typical, varies by region
  • Dimensions: 110 mm x 64 mm x 21 mm (H x W x D)
  • Weight: 75 g, without batteries
  • Housing: Molded ABS
  • Power Requirements: 2 LR6 AA batteries, 1.5 V, alkaline
  • Battery Life: up to 14 hours (alkaline)
