NBE-M5-300 - Ubiquiti NanoBeam M5 5GHz 22dBi AirMax CPE
Description
The new NanoBeam M has a compact, all-in-one design with uniform beam width, efficient footprint and a faster processor. The NanoBeam can be easily mounted in a variety of ways thanks to the innovative mechanical design. This version of NanoBeam has 300mm dish with 22dbi gain and it's total output power is 26dbm.
Long Distance Capable of high-speed, carrier-class links. Innovative Mechanical Design:
- All-in-one design: The NanoBeam provides both the radio and antenna in the smallest possible footprint.
- Quick and easy installation: No fasteners are required for pole-mounting, and a single wall fastener (not included) is required for wall-mounting.
- Convenient alignment: The NanoBeam pivots on its ball joint for easy aiming.
Compact Form Factor of NanoBeam:
- Efficient footprint: The radio and antenna are combined into a single body that takes up minimal space.
- Versatile mounting: The NanoBeam can be mounted in almost any position needed for line of sight.
- Aesthetics: The NanoBeam is small enough to blend discreetly into the background at a customer's location.
NanoBeam Features:
- Uniform Beamwidth Improves Noise Immunity
- More Efficient Footprint
- Faster Processor Increases Performance
- Easy Assembly and Installation
Specifications
| NanoBeam Specifications: |
| Processor |
Atheros MIPS 74KC, 560 MHz |
| Memory |
64 MB DDR2, 8 MB Flash |
| RoHS Compliance |
Yes |
| Power Supply |
24V, 0.5A PoE |
| Power Method |
Passive PoE (Pairs 4, 5+; 7, 8 Return) |
| Max. Power Consumption |
6W |
| Frequency |
5.47-5.825GHz |
| Gain |
22 dBi |
| Temperature |
40 to 70° C |
| Polarization |
Dual Linear |
| LEDs |
(1) Power, (1) LAN, (4) WLAN |
| Channel Sizes |
5/8/10/20/30/40 MHz |
