MB1000 prevents critical equipment from losing setup configuration, stored data and hard-disk crashes. Shuts off projection equipment via IR control to allow the projector bulbs to go through a proper cool-down cycle before shutting off.
Product Data Sheet HERE
Residential Systems Resi Award 2009
Winner — Best Power Management Product
Panamax UPS Family
Dual Learning IR Output Controls
RS-232 with Open Source Code Protocol
Power Management Software
RS-232 Pin Cable Included
General
| Weight |
36 lbs. |
| Dimensions |
17”W x 13”D x 4”H |
Input
| Voltage |
85-137 Vac |
| Frequency |
57-63 Hz |
AC Power
| Undervoltage Shutoff |
90 ±5V |
| Surge Protection |
900 Joules |
| Overvoltage Shutoff, slow rise |
132 ±5V |
| Overvoltage Shutoff, fast rise |
150 ±5V |
| Noise Attenuation: |
40dB min from 100kHz-2MHz
65dB max @ 270kHz |
| Current Rating |
12A |
| Automatic Voltage Regulation, Standard Mode Output Range |
120 ±10% |
| Automatic Voltage Regulation, Standard Mode Capture Range |
93-145V |
| Automatic Voltage Regulation, Sensitive Mode Output Range |
120 ±5% |
| Automatic Voltage Regulation, Sensitive Mode Capture Range |
98-135V |
UPS Output
| Voltage |
120 ±5V, Simulated Sine Wave |
| UPS Output Capacity |
1000VA 600W @ 0.6pf |
| UPS Backup Time |
3 minutes at full load |
| Transfer Time |
<10ms |
| Frequency |
60 Hz ±1% |
