Single-zone maximum output power
(0.1% THD+N; f=1 kHz)
50 W per channel, 2 channels at 8 ohms
80 W per channel, 2 channels at 4 ohms
140 W at 8 ohms, 2 channels bridged
All zones continuous output power
35 W per channel, 12 channels at 8 ohms
50 W per channel, 12 channels at 4 ohms
100 W at 8 ohms, each zone bridged
Distortion
<0.05% THD+N from 20 Hz to 20 kHz
Signal-to-noise ratio
>100 dB
Frequency response
20 Hz to 20 kHz +/-0.3 dB
Input sensitivity
70 mV for 1 W at 8 ohms
500 mV for 50 W at 8 ohms
Line input impedance
47 kilohms
Voltage gain
32 dB
Delay time
0.5 to 4.5 minutes
Input trigger
12 VDC 10 kilohms
Output trigger
12 VDC 100 mA
Power requirements
North America
120 VAC 60 Hz 5 A
Fuse rating: T10AL 250 V
Europe
230 VAC 50 Hz 2.5 A
Fuse rating: T7AL 250 V
Dimensions:
17" W x 5.875"H x 16.5"D
(43 x 15 x 42 cm)
3U rack space
Weight
38.1 lb (17.3 kg)
